Thor400-32S

Restock on 1st of Every month. Ship-out within 2 weeks of ordering

Please read warranty carefully for DIY items below.

Please DO NOT run a High Voltage Battery without a Fuse!

Thor400-32S includes:

Thor400-32S ESC; Momentary Power Switch; Thermal pad for mounting.
Getting the Thor400 ready to run is not for beginners. Especially combined with High Voltage batteries, it is recommended for beginners to opt for Thor400 mounted and ready to go (minus configuration), please take a look at the complete Thor400 Controller Boxes here. Or at our complete Powertrains or Boards.

Thor400-32S in Complete Fungineers Controller box includes:

Thor400-32S ESC in the Fungineers Die-cast metal box, fully mounted with world-class thermal interface for maximum cooling, with Front and Status LEDs mounted, Power switch and a 4pin GX-16 Aviation charge port (please select suitable charger). Complete with lid and gasket, Superflux Connector, M20 Cable gland for battery cable entry, 5-pin XR style footpad connector that works with Stompies/ XR style footpads.

If you really want to DIY the mounting, you can purchase the Thor400 only on this page; While mounting, it is mandatory to please go through user guide here.

Specifications and History:

December 2023: A big problem in the community - folks want to build Higher Voltage builds, but there are no suitable ESCs available..

A few months later, an e-scooter/ e-bike controller emerges that people start using for HV builds. Great controller! However, it's big, bulky, doesnt fit most connectors/ enclosures. No dedicated footpad connector/ hall sensor ports dont match, no direct LED support, etc...

Early 2024: I get on a call with our internal design team. Here's how the call goes:

Me- We want a a controller capable of 32S/ 135V, and upto 400 amps abs. max. A DEDICATED Funwheel/ VESC-wheel controller.

Designer - Sure that can be done.

Me- ...and we want it in the same space and same bolt pattern and layout as the Thor300.

Designer-..that...might be impossible...

Well, that's how it began, a lot of impossible things later, the Thor400-32S was born. Here are some mind blowing specs:

• True 32S controller (with all HV components rated to 150V! perhaps the only one in the industry...perhaps).
• Extremely expensive and reliable OnSemi Dual cool Automotive Tech FETs. We have 18 of these FETs in this extremely small package. Providing unrivaled power with TOLT/ Dual cool technology. Forget overheating controllers.
• 400A abs. max current (depending on cooling/ Fungineers box is recommended).
• Same bolting pattern and size as the Thor300. Fits in the Fungineers box and still has space for 2S2P 21700 (400A in this package is unheard of!).
• Same onboard LED support as the Thor300 (just plug in the status, front, and rear led).
• 12V led ready. Choice to run 5V (can be switched with shifting a resistor. Soldering skills needed)
• ESP32 breakout pins to run additional functions.
• 12V/ 5V additional pads to run 5A (max with cooling) LEDs or other functions!
• Sin/Cos encoder Support.
• Additional temperature probe support (to monitor temperature of your split pack).
• ebike throttle support (Can be switched with a jumper).
• Improved robustness and design - stronger, and more rigid than ever.
• Momentary button: Same button and pins as the Thor300, but improved hardware and logic.
• VESC Express onboard Bluetooth/ Wifi module; preconfigured.

In short, the Thor400 is NOT for Onewheels/ Funwheels. This is an ebike/ EUC worthy Controller that will turn your Funwheel into an absolute beast; and you can be sure your Funwheel is 100% future proof with the Thor400 due to the bleeding edge features.

Warranty

We love the community we serve but due to the DiY and dangerous nature of things, we cannot guarantee that products will be installed and configured correctly. Therefore, we urge you to please follow the user guide while installing and request to buy the complete Thor400 box or Powertrain or complete boards. We will offer a 1 year warranty cover provided proper install guidelines were followed as per the Thor400 User guide.
